StepSmootherGain

Created Donnerstag 30 Juni 2016

Smoothly activate and deactivate a Real signal.

1. Purpose of Block

Applicable if a variable shall be conditionally and smoothly reduced to zero.

2. Limits of Validity / Features

3. Interfaces

4. Nomenclature


5. Governing Equations

The block's output is zero as long as the input x is smaller than the input noFunc. The output y will equal the input u if x is greater than func:

For a smooth transition between 0 and u at the output he block makes usage of ClaRa's smoothing function, i.e.
y=Stepsmoother(func, noFunc, x)*u.
See a simple example of the block's application below.
